Introducing the FORMART 2: the ultimate all-in-one vacuum former for your home or maker space. Thanks to its fast heating element, large working area and built-in vacuum pump, this vacuum forming machine is a complete solution. No need for connecting vacuum cleaners or other clunky setups. Beginners and professionals alike will be able to create freely with our FORMART 2, thanks to its user-friendly design and built-in features.
Automatic
mold releasing
Fast
cooling system
Automatic
material detection
Built-in
pressure sensor
With its built-in directional valve, the FORMART 2 will automatically blow cooling air after vacuum forming, which allows you to remove the mold more easily.
The FORMART 2 vacuum former has the world’s first plastic sheet identification sensor. All working parameters are loaded in an instant by scanning the QR code on the MY YARD material.
The built-in dual brushless fans will cool your object fast and greatly enhance your productivity.
Three suction modes, stepless pressure adjustment.
FORMART 2’s built-in vacuum sensor allows you to define the suction force at any level. This maximises the flexibility of mold material selection.
18.50 inch x 10.63 inch
These cutting-edge vacuum forming machines boast the largest work area for a desktop vacuum former and a unique size-switching function. You can adjust the size of the work area, minimising any unnecessary waste.
The 18.50 x 10.63 inch work area gives you plenty of creative space, from delicate earrings to expansive lampshades.
The patented quick-locking frame allows you to lock the plastic sheet immediately by turning the handle.
In addition, the frame can be stopped at any height, so you can quickly put in the next sheet without removing your forming object, which is really efficient!
Our FORMART 2 not only provides great suction power, it also gives you the ability to control the vacuum level.
The FORMART 2 has industrial-grade suction power up to -90 kPa, but it also has integrated vacuum sensors and flow control technology that allows you to define the ideal vacuum level for your project.
Don't worry if you are not a professional user, FORMART 2 offers three intelligent suction modes. Just press the button and our vacuum forming machine will take care of the complicated parameters for you.
Thanks to their industrial-grade carbon fibre quartz heating tube, our vacuum formers heat up three times faster than our competitors! The even heating ensures the forming quality is as good as professional machines.
The built-in preheating process significantly improves the forming quality and allows more materials to be formed, making our FORMART 2 suitable for a large variety of materials.
The FORMART 2 has the most complete built-in database for materials. Whether you’re using original or third-party plastic sheets, the FORMART 2 can handle it. In addition, it is capable of storing up to five sets of user settings, allowing you to customise your working parameters.
Our FORMART 2 has a built-in plastic sheet dehumidification function. This automatically removes moisture from your plastic sheet and prevents air bubble defects during forming.
Select the operation mode and task
Insert your material into your FORMART 2
Start the preheating program and raise the frame to warm up the material
Pull the heated material over the object on the forming bed
Wait until the sheet has been pulled tight
Ready! Now you can start bringing your ideas to life
 FORMART S |
 FORMART SE |
FORMART 2 |
|---|---|---|
| Dimensions | ||
| 19.76 x 18.27 x 12.28 inch | 24.80 x 18.90 x 20.87 inch | 24.80 x 18.90 x 20.87 inch |
| Work area | ||
| 11.81 x 8.07 inch | 18.50 x 10.63 inch Adjustable |
18.50 x 10.63 inch Adjustable |
| Max. object height | ||
| 6.30 inch | 6.30 inch | 6.30 inch |
| Weight | ||
| 28.22 lb | 52.91 lb | 55.12 lb |
| Sheet Thickness | ||
| 0.01 x 0.12 inch | 0.01 x 0.12 inch | 0.01 x 0.12 inch |
| Sheet Size | ||
| 1 size 12 x 8 inch |
4 sizes 19.75 x 12 inch 16.5 x 12 inch 12 x 12 inch 12 x 8 inch |
4 sizes 19.75 x 12 inch 16.5 x 12 inch 12 x 12 inch 12 x 8 inch |
| Pump Type | ||
| AC induction pump | DC brushless pump + AC induction pump |
DC brushless pump + AC induction pump |
| Display | ||
| 3.5” 480 x 320 Full Color LCD | 3.5” 480 x 320 Full Color LCD | 3.5” 480 x 320 Full Color LCD |
| Heater Type | ||
| Quartz heater tubes, temperature range 140 - 446 °F |
Quartz heater tubes, temperature range 140 - 446 °F |
Quartz heater tubes, temperature range 140 - 446 °F |
| Suction Mode | ||
| -90 kPA Flow rate adjustable |
-90 kPA 3 steps selectable |
-90 kPA Pressure adjustable |
| Power Supply | ||
| 100 - 120 V AC @ 800 W 220 - 240 V AC @ 800 W |
100 - 120 V AC @ 1500 W 220 - 240 V AC @ 1700 W |
100 - 120 V AC @ 1500 W 220 - 240 V AC @ 1700 W |
| Other features | ||
| CNC wooden forming bed | Alert speaker |
|
