FORMART S is a powerful, versatile and ultra-compact vacuum former using 12 x 8 inch-sized materials. Achieve molds with incredible detail with its built-in industrial-grade vacuum pump. The intuitive interface lets you create pro-level molds easily. From beginners to professionals: unleash your creativity without limits!
CNC wooden
forming bed
12 x 8 inch-sized
materials
Compact and
space saving
Integrated
vacuum pump
The wooden CNC base plate absorbs less heat, which allows your molds to have finer and more intricate details.
Unlike the larger FORMART SE and FORMART 2 vacuum formers, the FORMART S uses 12 x 8 inch-size sheets. The advantage is that smaller sheets are easy to find and as always you can use both original and third-party materials.
Made for 12 x 8 inch plastic sheets, the FORMART S vacuum former has a vacuuming area of 10.24 x 6.61 inch, offering a substantial working area in a small package.
With its tiny footprint the FORMART S is easy to store and the perfect size for your (home) office. Create professional molds right from your desk.
Achieve molds with unprecedented detail, thanks to the built-in industrial grade AC induction pump with -90 kPa suction power.
The patented dual-locking frame ensures a secure grip on the plastic sheet and allows you to lock it immediately by turning the handle. The magnetic clamps provide tray stability.
In addition, the frame can be stopped at any height with a twist of the wrist, so you can quickly put in the next sheet without removing your forming object.
Thanks to the industrial-grade carbon fibre quartz heating tube, the FORMART S heats up three times faster than its competitors! The even heating ensures professional forming quality and helps you to minimise waste.
With the 3-minute rapid heating you can create professional level molds in no time.
Professional and convenient at the same time! The "Advanced Mode" gives you maximum flexibility for professional use, while the "Simple Mode" has three built-in smart modules to help you get started quickly.
The built-in preheating process significantly improves the forming quality and allows more materials to be formed, making the FORMART S suitable for a large variety of materials.
The FORMART S vacuum former has an extensive built-in materials database with 17 presets. Whether you’re using original or third-party 12 x 8 inch plastic sheets, the FORMART S can handle it.
The FORMART S has a built-in plastic sheet dehumidification function. This automatically removes moisture from your plastic sheet and prevents air bubble defects during forming.
Select the operation mode and task
Insert your 12 x 8 inch-sized material into your FORMART S
Start the preheating program and raise the frame to warm up the material
Pull the heated material over the object on the forming bed
Wait until the sheet has been pulled tight
Ready! Now you can start bringing your ideas to life
|
FORMART S |
 FORMART SE |
 FORMART 2 |
|---|---|---|
| Dimensions | ||
| 19,76 x 18,27 x 12,28 inch | 24.80 x 18.90 x 20.87 inch | 24.80 x 18.90 x 20.87 inch |
| Weight | ||
| 28.22 lb | 52,91 lb | 55.12 lb |
| Sheet Thickness | ||
| 0.01 x 0.12 inch | 0.01 x 0.12 inch | 0.01 x 0.12 inch |
| Sheet Size | ||
| 1 size 12 x 8 inch |
4 sizes 19.75 x 12 inch 16,5 x 12 inch 12 x 12 inch 12 x 8 inch |
4 sizes 19.75 x 12 inch 16,5 x 12 inch 12 x 12 inch 12 x 8 inch |
| Pump Type | ||
| AC induction pump | DC brushless pump + AC induction pump |
DC brushless pump + AC induction pump |
| Display | ||
| 3.5” 480 x 320 Full Color LCD | 3.5” 480 x 320 Full Color LCD | 3.5” 480 x 320 Full Color LCD |
| Heater Type | ||
| Quartz heater tubes, temperature range 140 - 446 °F |
Quartz heater tubes, temperature range 140 - 446 °F |
Quartz heater tubes, temperature range 140 - 446 °F |
| Suction Mode | ||
| -90 kPA Flow rate adjustable |
-90 kPA 3 steps selectable |
-90 kPA Pressure adjustable |
| Power Supply | ||
| 100 - 120 V AC @ 800 W 220 - 240 V AC @ 800 W |
100 - 120 V AC @ 1500 W 220 - 240 V AC @ 1700 W |
100 - 120 V AC @ 1500 W 220 - 240 V AC @ 1700 W |
| Other features | ||
| CNC wooden forming bed | Alert speaker |
|
